SUN RUN S200-50 Hydraulic Cylinder 200 ton dengan stroke 50mm, kuat dan presisi untuk aplikasi industri berat. Finishing anti karat, seal rapat, dan daya tahan tinggi untuk kerja maksimal.
- Model Number: S200-50 Sun Run
- Cylinder Capacity: 200 ton (1984 kN)
- Stroke: 50.0 mm
- Effective Area: 283.38 cm²
- Oil Capacity: 1416.9 cm³
- Collapsed Height: 200.0 mm
- Extended Height: 250.0 mm
- Outside Diameter: 255.0 mm
- Cylinder Bore Diameter: 190.0 mm
- Plunger Diameter: 135.0 mm
- Base to Advance Port: 50.0 mm
- Saddle Diameter: 115 mm
- Single-Acting Cylinders – General Features
- Designed for use in all positions.
- Hard chrome plated plunger and barrel interior resist wear and corrosion, ensuring tighter sealing and extended cylinder life.
- Maximum-sized springs provide faster piston return and longer spring life.
- Special soft ring reduces wear caused by off-center loads.
- Plunger wiper minimizes contaminant entry.
- Stop ring provides piston blow-out protection.
- Powder-coated finish enhances corrosion resistance and rust protection.
- All cylinders are equipped with SQB-3/8UF female coupler & dust cap.
