Hydraulic cylinder SUN RUN RSC-53 kapasitas 5 ton dengan stroke 76 mm. Desain compact, kuat, dan presisi untuk kebutuhan lifting industri maupun perawatan mesin.
- Model Number: RSC-53 Sun Run
- Cylinder Capacity: 5 ton (45 kN)
- Stroke: 76 mm
- Cylinder Effective Area: 6.5 cm²
- Oil Capacity: 50 cm³
- Collapsed Height: 165 mm
- Extended Height: 241 mm
- Outside Diameter: 38 mm
- Cylinder Bore Diameter: 28.7 mm
- Plunger Diameter: 25.4 mm
- Base to Adv. Port: 19 mm
- Saddle Diameter: 25 mm
- Saddle Protrusion from Plunger: 6 mm
- Plunger Internal Thread: 3/4″-16 in
- Plunger Thread Length: 14 mm
- Collar Thread: 1¹/₂”-16 in
- Collar Thread Length: 28 mm
- Bolt Circle: 25 mm
- Thread: 1/4″-20 UN in
- Thread Depth: 14 mm
- Single-Acting, Spring Return Collar Thread Cylinders:
- Equip with collar thread and base holes (on most models) for greater mounting flexibility.
- Equip with inner plunger thread (5 ton to 30 ton) for greater fixture design flexibility.
- Bronze alloy bearing on plunger to minimize scoring due to off-centre load.
- Hard chrome plated plunger to resist wear and corrosion.
- Inner barrel wall hard chrome plated for corrosion resistance in high-humidity environments.
- Wiper seals to prevent dirt ingress.
- Stop-ring to prevent plunger blow-out and withstand full “dead-end” load.
- Powder-coated finish for improved corrosion protection.
- Plastic cap to protect collar threads.
- Come with SQB-3/8UF female coupler & dust cap.
